Freenove Universal Breakout Board Compatible with Arduino Nano Micro Raspberry Pi Pico 1 2 W ESP32 ESP8266, Terminal Block Shield HAT with Pin Header, GPIO Status LED, 5 V 3.3 V(for ESP32 / ESP32-S3)
$12.95
🌸 Cute & Stylish Hair Accessories
🚚 Free Shipping on $12.95 📦 Ships in 3–5 Days
🔍 Carefully Inspected 💫 21-Day Returns
Product details
Brand: FREENOVE
Model Name: FNK0101
Connectivity Technology: WiMax
Included Components: board
Operating System: Linux
About this item
Compatible Models: Any board (5 V or 3.3 V) with a pin spacing of 0.1 inch (2.54 mm), width 0.6, 0.7, 0.8, 0.9, 1.0 inch and length up to 2.3 inch (24 pin) (Compatible with Arduino Nano / Micro, Raspberry Pi Pico 1 / 2 (W), ESP32, ESP8266)
Power Supply: If using DC input (6~24 V), can provide 5 V and 3.3 V power (DC-DC circuit, up to 3A); otherwise, can use the power of the main board (Need to configure jumper caps, please refer to the tutorial)
GPIO Status LED: LED on if GPIO outputs / inputs high level, LED off if GPIO outputs / inputs low level
Independent LED: The status LED is driven by the chip instead of the GPIO so the GPIO will not be affected
Terminal Block and Header: Connect to all pins of the main board, 2.54 mm (0.1 inch) pitch
